tesa 4970 PVC tape white

SKU
AW04970CONFIG
More than 1372 mm left
€8.83 €7.30

Tesa 4970 is a thick white double-sided self-adhesive tape consisting of a PVC foil backing and a tackified acrylic adhesive.

Total available width in stock 1973 mm
Calculate your product and see the available stock
-
+
Click here to order a Sample "laser part" chevron_right Order now!
Details
Tesa 4970 is a thick white double-sided self-adhesive tape consisting of a PVC film backing and a tackified acrylic adhesive. Tesa®4970 features in particular: Excellent combination of high bonding strength and direct adhesive strength High coating weight for effective bonding on rough or dusty surfaces Fully suitable for long-term applications Main applications Mounting of plastic and wooden finishes Mounting of decorative POS materials en displays Mounting of signs and bowls Technical data PVC film backing Colour white Total thickness 225 µm Type of adhesive tackified acryl Cracking stretch 20% Stretching force 38 N/cm Type of lining film Colour of lining brown Thickness of lining 71 µm Weight of lining 82 g/m² Adhesive strength on steel (direct) 13.0 N/cm ABS (direct) 13.4 N/cm aluminium (direct) 11.5 N/cm PC (direct) 16.2 N/cm PE (direct) 8.5 N/cm PET (direct) 11.5 N/cm PP (direct) 9.7 N/cm PS (direct) 14.7 N/cm PVC (direct) 12.4 N/cm steel (after 14 days) 13.6 N/cm ABS (after 14 days) 14.4 N/cm aluminium (after 14 days) 12.6 N/cm PC (after 14 days) 16.9 N/cm PE (after 14 days) 9.1 N/cm PET (after 14 days) 11.9 N/cm PP (after 14 days) 10.8 N/cm PS (after 14 days) 15.2 N/cm PVC (after 14 days) 16.6 N/cm
More Information
More Information
SKU AW04970CONFIG
GTIN-EAN / UPC 4042448406026
Shortid TESAFIX 4970
MPN-Manufacturer part number 04970-00033-00
Condition New
Expected delivery date 05-06-2026
Production tolerances: Cutting Roll width up to 100mm +/- 1.0mm and above 100mm +/- 2.0mm.
Roll width outer diameter with respect to roll width core diameter +/- 1.0mm.
Water is used. This can leave "stains", but does not affect the adhesive result
Most sold in the branch(ses) Contruction, Printing, Project design & Home furnishings, Exhibition and Advertising
Width (mm) 1372
Length (m) 50
Thickness (mm) 0.225
Brand tesa
adhesive Acrylic
carrier PVC
liner Paper
Color White
adhesion to steel (N/100 mm) 13
Elongation at break (%) 20
Treksterkte (N/cm²) 38
Temperature resistance ° C lang + 60°C, kort + 70°C
Special characteristics UV-Resistent
remaining Bestand tegen chemicaliën +, vochtbestendigheid ++
