tesa 60252 Double-sided Electrically Conductive Tape | Tapir Tapes
SKU
AW602521040050
Out of stock
tesa 60252 is a double-sided, electrically conductive tape for demanding applications. Perfect for EMC, grounding and ESD. Order now at Tapir Tapes!
tesa 60252 is a high-quality, double-sided, electrically conductive tape that offers excellent performance in demanding EMC and ESD environments. The tape consists of an electrically conductive woven backing and an electrically conductive acrylic adhesive, which ensures a reliable connection and excellent electrical conductivity.
Main applications
- EMC applications, such as grounding
- Electrostatic discharge (ESD) applications
Technical properties
- Thickness: 55 µm
- Backing: Conductive woven
- Colour: Grey
- Adhesive: Conductive acrylic
- Temperature resistance (short-term): 180 °C
- Adhesive force on steel (after 14 days): 8.5 N/cm
- Surface resistance: 0.2 Ohm/square
- Contact resistance: 0.05 Ohm/square inch
Advantages
- Excellent electrical conductivity in all directions (x, y and z)
- High adhesion on various surfaces
- Easy to process and apply
- Durable and reliable, even under tough conditions
Tapir Tapes: Your partner for professional tapes
At Tapir Tapes you will find a wide range of high-quality tapes for various applications. Order tesa 60252 today and benefit from our fast delivery and competitive prices.
| SKU | AW602521040050 |
|---|---|
| Condition | New |
| Expected delivery date | 08-06-2026 |
| Most sold in the branch(ses) | Electronics, LED-lighting, Wind- and solar energy |
| Width (mm) | 1040 |
| Length (m) | 50 |
| adhesive | Acrylic |
| carrier | conductive woven |
| liner | Foil |
| Thickness (mm) | 0.055 |
| Color | Gray |
| adhesion to steel (N/100 mm) | 8.5 |
| Temperature resistance ° C | kort 180 °C |
| Special characteristics | Type voering poly-gecoat papier |
| remaining | Oppervlakteweerstand (x-y richting): 0.2 Ohm/square |
| Brand | tesa |
